Ductless Fume Hood School-Style (Educational Version)
TopAir's 360° glass, inverted, ductless fume hood for educational purposes is an effective tool for education and provides a safe environment for laboratory personnel working with acids and harsh chemicals.
The unit features a 7-inch color touchscreen operating system to control the entire system:
Airflow alarm and indicator
Air chamber alarm (red)
Light activation
Flueless Fume Hood Technical Specifications:
Highly chemically resistant 8 mm welded polypropylene
Double back wall with compartment
Internally sealed polypropylene countertop or epoxy, stainless steel, ceramic, and HPL options
Tempered glass, counterweighted, fully opening sliding front sash
7-inch color touchscreen
• Air speed indicator and alarm
• 360° Clear glass
• High-efficiency, quiet ECM fan
• 800 lux LED lighting
• Easy front access for filter replacement
• Carbon blend filter (22 kg) and pre-filter for training purposes
• Complies with BS7989:2001 and CLEAPSS.
Specifications/Model Model CF-120-PRO-RV
External Dimensions
Width x Depth x Height 1200 x 800 x 2270 mm 47.2 x 31.5 x 89.4 in
Working Area
Width x Depth x Height 1160 x 600 x 1100 mm 45.7 x 23.6 x 43.3 in
Front Wing Maximum Minimum Working Height: 200 mm /
Maximum Working Height: 350 mm
BS7989:2001 and CLEAPSS Test Standard Compliance
Air Velocity Airflow indicator and alarm 0.5±0.1 m/s, 100±20 fpm
Bonnet Material Welded white anti-corrosion polypropylene construction with internal gasket, polypropylene countertop
360° View 5 mm tempered safety glass / 360° view with polycarbonate
Power Supply: 110/220V, 50/60Hz, single-phase
Lighting: 800 LUX, Eco-Friendly LED lighting
Activated carbon filter and HEPA filter available for various chemicals and solvents.
