Tezmobil 01 Stainless Steel Body Local Suction Arm Air Cleaner
This mobile stainless steel body local suction unit, available with many add-on options, enables the capture and filtration of dust, smoke, and harmful gas emissions at the source in laboratories, test and R&D centers, laboratories with strong odors, cosmetic, fragrance, paint, or sensitive industrial working environments.
Tezmobil 01 Stainless Steel Body Local Suction Arm Air Cleaner Technical Specifications
Cabinet Dimensions: 500 mm (Width) x 500 mm (Depth) x 700 mm (Height)
The product can be manufactured in different sizes.
Body Structure: Stainless steel (AISI 304/316 quality, matte/brushed surface).
The product can be manufactured as galvanized steel with electrostatic powder coating.
Mobility: The cabinet has 4 industrial-grade wheels that rotate 360° under the cabinet, at least 2 of which can remain fixed in position thanks to a brake locking mechanism.
Local Suction Arm: Mounted on the top panel of the cabinet, it will have a multi-jointed (acrobat) structure that rotates 360° and can be fixed at the desired angle. This arm is made of aluminum, with its joints and moving parts made of polypropylene/equivalent materials, and is used in many laboratories in Turkey. It can be optionally paired with Fumex Terfu or Nederman brand products. The arm length is 150 cm and can reach hard-to-reach points thanks to at least 2/3 joints.
The local suction arm provides suction of vapor and smoke towards the main body thanks to the transparent polycarbonate/PVC cap/hood at the end. Several options are available for this transparent cap at the end. For detailed information, please contact our laboratory installation specialist sales team. Ventilation Grilles: The side panels of the cabin will feature stainless steel slat/grille structures providing engine cooling and air circulation.
Technical Specifications and Standards
Mobile Body Material: AISI 304 / 316 Stainless Steel (Galvanized Steel with Electrostatic Powder Coating, Heavy Duty and Industrial Type)
Cabinet Dimensions: 500 x 500 x 700 mm
Local Suction Arm Diameter: Different Arm Diameters (75mm / 100 mm): Standard or PP or Atex (In Atex products, only the material for the local suction is Atex certified, not the entire device.)
Hood (Shield): Transparent Polycarbonate / Acrylic Conical Hood (with Flap)
Movement System: 4 Swivel Wheels (2 with Brakes) (Optional: all wheels can be produced with brakes)
Filter Structure: Pre-filter (G4) + Activated Carbon / HEPA (H13) HEPA (H14) Filter Module
Fan / Motor Type: Low Noise Vertical/Radial Fan
Power Supply & Control: 220V / 50 Hz Single-Phase, Illuminated ON/OFF Switch
